This 0.96″ 128×64 OLED Display Module is designed for Raspberry Pi projects where a compact, low-power screen is needed to show system information such as IP addresses, CPU temperature, and status messages. The SSD1306 controller communicates via 4-wire SPI, keeping wiring simple and data transfer fast.

With ultra-low power consumption, a high-contrast display, and an extremely wide viewing angle, this module is ideal for portable Pi projects where a full-sized monitor would be impractical.

Key Features

• 0.96″ OLED Display – 128×64 pixel resolution with high contrast
• SSD1306 Controller – Widely supported with Python and C libraries
• 4-Wire SPI Interface – Fast communication at up to 64 MHz (typical)
• Ultra-Low Power – 12.25 µA continuous, 100 µA maximum
• 3.3V Operation – Direct compatibility with Raspberry Pi GPIO (1.6–3.6V range)
• Internal DC/DC Converter – No external voltage regulation required

Specifications

• Display Size: 0.96″
• Resolution: 128×64 pixels
• Driver IC: SSD1306
• Interface: 4-wire SPI
• Operating Voltage: 3.3V (1.6–3.6V)
• Continuous Current: 12.25 µA
• Maximum Current: 100 µA
• Frame Rate: 64 fps (typical)

Ideal For

• Raspberry Pi system status displays
• Portable and headless Pi projects
• Network monitoring (IP address, connectivity)
• IoT dashboards and sensor readouts

Package Contents

• 1× 0.96″ OLED Display Module for Raspberry Pi

Resources

• DFRobot Wiki – Setup Guide and Tutorial
